• Take-Up Units
As chains become worn out, the chain length will extend and it also stretches when subjected to tension. Therefore, in order
to maintain continuous and smooth operations, it is necessary to apply force to the chain after the chain leaves the drive unit.
This is where the Take-Up device comes into play. It absorbs the elongation of the chain, and maintains proper chain tension.
This helps ensure smooth conveyor operation and reduces the possibility of chain blockages.
Take-Up devices can be used with pneumatic, counter-weight, and spring-operated tension adjustment methods to meet the
needs of a variety of applications.

Item NO. Description Item NO. Description

X-348 Take-Up Device
601260002 5011101116 X-348 Expansion Tube Set
(Spring Type)

X-458 Take-Up Device
601270002 5011101117 X-458 Expansion Tube Set
(Spring Type)

X-678 Take-Up Device
601280002 5011101118 X-678 Expansion Tube Set
(Spring Type)

X-348 Take-Up Device
X-458 Take-Up ( Roller Turn)
Inverted Conveyor System
(Take-Up Device)

X-348 Take-Up Device
X-458 Inverted Conveyor System
X-458 Expansion Tube Set

X-348 Take-Up Device
(Counter Weight)
X-458 Inverted Take-Up Device
