Page 51 - 2020 Product catalog

H
I ØA

X-678 I-BEAM

J
B X-678
K G Center Link
C
D

E F

L (Unit mm)

Load Capacity
Item NO. Description A B C D E F G H I J K L
Pair (kg)
X-678 Trolley with H Attachment
6013602AC1 125 170.2 41.28 69.85 92.1 85.8 102.2 175 126.3 29 13 22.6 600
102.2 Drop (125 Bearing)
X-678 Trolley with H Attachemnt
6013602AC8 122 170.2 41.28 69.85 92.1 85.8 103.7 175 126.3 29 13 22.6 600
103.7 Drop (122 Bearing)
X-678 Trolley with H Attachment
6013601AC2 125 169.8 41.28 69.85 92.1 85.85 101.5 175.1 127.3 29 13 22.6 600
101.5 Drop (1760 Bracket)
X-678 Trolley with H Attachment
6013601AC3 125 169.8 41.28 69.85 92.1 85.85 101.5 175.1 127.3 29 13 22.6 600
101.5 Drop (1460 Bracket)

• P2-160 Half Trolley-140 Bearing
Item NO. 6013601AA1
Load Capacity Pair (kg) 600

85
48
Ø140

Ø112 Ø55

137
193
2-Ø15
P2-160
45 84 50 Center Link
12
90 (Unit mm)

Power Trolleys 50
