INDUSTRIAL CONVEYOR CHAINS

L
ØF
D K
E
ØJ
2-ØH L
G
I

C
A B
(Unit mm)

Min. Ultimate
Surface
Item NO. Description A B C D E F G H I J K L Material Tensile
Finishing
Strength (kgf)
RF6205F-5LA2
5014240001 Conveyor Chain 152.4 152.4 44.5 83.5 60 15.9 60 15 100 57.2 37.1 7.9 SAE1045 Anti-Rust 19000
with A2 Attachment Oil
RF05150R-1LA2 Anti-Rust
5014240005 Conveyor Chain 150 150 32 53.5 35 11.3 60 10 85 40 22 4.5 SAE1045 Oil 7000
with A2 Attachment

• HR35088F-GA4 Lift Chain
Item NO. 50620080004
Material SCM440/420
Surface Finishing Anti-Rust Oil
Min. Ultimate Tensile Strength (kgf) 32000

25.4 12.7

14
156 A 60° Ø40

Ø28
94.8 MIN Ø28 350 350 260 Ø28 66.7 MIN 92.8 MAX Ø28 12.7
200

A
240 170 76.2 Ø160 Ø125

Ø38.5
426.2 14
42
(Unit mm)
